products

iSyncWaveTM

100% Wireless dry EEG measurement and therapeutics device

Soft fitting, expandible, wireless,
dry EEG device with Near-infrared Photobiomodulation
AI Brain Scanning & Enhancing System

iSyncWaveTM is the first-ever integrated EEG and neurotherapeutics device providing telemental care through an AI digital brain health platform. A QEEG guided PBM Light therapy function is included for activating mitochondria and microglia activities in the brain.

KFDA 21-5051

iSyncWave

Specialties

Quick & Easy EEG

Appreciated by both
clients and clinicians

Flexible fit for all

Comfortable for all head size

Clinical signal quality

All the precision
compared to wet standard

Measure and analyze
in 10 min.

Seamless standardized
analysis via the cloud

Al-driven analysis &
summaries

Unique health snapshot:
3D QEEG Brain Mapping
Heart & emotions

HRV measurement

Integrated stress and
hoort health assessments

Telecare-ready for
remote service provision

Pre & Post intervention
monitoring via client-friendly
dry EEG monitoring

World’s first integrated
EEG-LED therapy solution

QEEG-guided location and
frequency protocols for
optimum therapeutic response

iSyncWave

Telemental care

iSyncWave

Personalized mental care solution

iSyncWave

Device details and Specifications

Fits on all ages and genders

International standardized 10/20 positioning using auto fit banding technology with expandible gear and complex spring structures

Dry-type Ag/AgCl coated conductive polymer

Soft dry electrode with Ag/AgCl coating ensures maximum comfort and a high-quality signal.

AFE(Analog Front End)

Analog filter and amplifier added on the conventional biosignal amplifier which enables more robust signal acquisitions in noisy environments.

HRV measurement using PPG channel

Pulse acquisition using PPG sensor simultaneously with 19 channel EEG recordings can monitor heart health and brain health.

Parameters Values
EEG & HRV Size
Weight 1600 g
Dimensions 245(L) x 243(W) x 153(H) mm
Head Circumference 50 cm – 62 cm
Channels
EEG 19 EEG Channels + 1 Fpz Ground Channel
Auxiliary Right: 1 PPG Channel / Left: A1 Reference Channel
EEG Electrode Dry-Type Ag/AgCl-Coated Conductive Polymer
Power
Battery Rechargeable Li-Ion Battery
Charging USB-C Type with 5V/2A Adapter
Charging Time 132 Min
Runtime 7 Hours
Amplifier
Bandwidth 0.5 – 50 Hz
Sampling Rate 250 Hz
Special Design Analog Front End (AFE)
A/D Converter 24 Bit
Connectivity
Bluetooth Bluetooth v5.0 (LE up to 2Mbps)
LED Irradiance Source 19 LED Bulbs (Built-in the center of each EEG electrode)
Wavelength Near-Infrared 850 nm
Pulse Rate 1 – 45 Hz (Adjustable in 1Hz Increments)
Parameters Values
Name of Software iSyncWave™ Download from google playstore
Compatible Devices Samsung Galaxy Tab S4, S6(5G, Lite), S7(+, FE 5G)
Samsung Galaxy Tab A (2016)/ Active Pro, 2,3
OS Android 8 or Above
Minimum Requirements
CPU Octa-Core / 2.3 GHz, 1.7 GHz
RAM 4 GB
Recommended Requirements
CPU Octa-Core / 3.09 GHz, 2.4GHz, 1.8 GHz
RAM 12 GB
