iSyncMe
iMediSync’s new product that creates the perfect harmony of lightness, accuracy and durability
Soft Fitting, Expandible, Wireless,
Dry EEG Device with Near-Infrared Photobiomodulation
AI Brain Scanning & Enhancing System
The newly released iSyncMe is the world’s first EEG measurement and Neurotherapy convergence solution and is a mental health care platform device capable of remote care.
It is a new product with improved signal quality accuracy with lighter weight and enhanced PBM performance.
![](https://www.imedisync.com/wp-content/uploads/2023/11/Floor_12-1.png)
iSyncMe
Features
![](https://www.imedisync.com/wp-content/uploads/2021/11/sub_iSyncWave_features01-2-1.png)
Quick & Easy EEG
Appreciated by both
clients and clinicians
![](https://www.imedisync.com/wp-content/uploads/2021/11/sub_iSyncWave_features02-2.png)
Flexible fit for all
Comfortable for all head size
![](https://www.imedisync.com/wp-content/uploads/2021/11/sub_iSyncWave_features03-2.png)
Excellent Signal Quality
All the precision
compared to wet standard
![](https://www.imedisync.com/wp-content/uploads/2022/12/sub_iSyncWave_features05-2.jpg)
Measure and analyze
in 10 min.
Seamless standardized
analysis via the cloud
![](https://www.imedisync.com/wp-content/uploads/2021/11/sub_iSyncWave_features06-2.png)
Al-driven analysis &
summaries
Unique health snapshot:
3D QEEG Brain Mapping
Heart & emotions
![](https://www.imedisync.com/wp-content/uploads/2021/11/sub_iSyncWave_features04-2.png)
HRV measurement
Integrated stress and
hoort health assessments
![](https://www.imedisync.com/wp-content/uploads/2021/11/sub_iSyncWave_features07-2.png)
Telecare-ready for
remote service provision
Pre & Post intervention
monitoring via client-friendly
dry EEG monitoring
![](https://www.imedisync.com/wp-content/uploads/2021/11/sub_iSyncWave_features08-2.png)
World’s first integrated
EEG-LED therapy solution
QEEG-guided location and
frequency protocols for
optimum therapeutic response
iSyncMe
Device details and Specifications
![](https://www.imedisync.com/wp-content/uploads/2023/11/sub_iSyncMe.png)
성별/연령 제한 없는 Fit한 착용
Auto Fit Banding 기술이 탑재되어 있어, 국제 10/20 전극 배치규격에 맞도록 밀착 확장가능하여 모든 성별/연령에서 사용 가능합니다.
건식 전극 타입 Ag/AgCl-Coated Conductive Polymer 사용
도전성 폴리머를 사용한 부드러운 소재의 전극으로 착용감을 개선하였으며, 전극 표면에 Ag/AgCl이 코팅되어 있어 우수한 신호품질을 얻을 수 있습니다.
AFE(Analog Front End)
종래의 뇌파계 회로구조에 AFE 아날로그 필터 및 증폭 회로를 추가하여 각종 잡음 환경에서도 뇌파 측정이 용이하도록 설계 되었습니다.
PPG 채널로 심박변이도 측정 가능
PPG 센서를 통해 맥파를 19채널 뇌파와 동시에 측정하여, 뇌건강과 동시에 심장건강을 확인합니다.
Parameters | Values | |
---|---|---|
EEG & HRV | Size | |
Weight | 1200 g | |
Dimensions | 235(L) x 225(W) x 149(H) mm | |
Head Circumference | 41.5 cm – 64.2 cm | |
Channels | ||
EEG | 19 EEG Channels + 1 Fpz Ground Channel | |
Auxiliary | Fpz Channel: PPG Ground / Right: No Channel / Left: Ref Channe | |
EEG Electrode | Dry-Type Ag/AgCl-Coated Conductive Polymer | |
Power | ||
Battery | Rechargeable Li-Ion Battery | |
Charging | USB-C Type with 5V/2.0A, 9V/1.5A Adapter | |
Charging Time | 90 min | |
Runtime | 7 Hours | |
Amplifier | ||
Bandwidth | 0.5 – 50 Hz | |
Sampling Rate | 250 Hz | |
Special Design | Analog Front End (AFE) | |
A/D Converter | 24 Bit | |
Connectivity | ||
Bluetooth | Bluetooth v5.1 (LE up to 2Mbps) | |
LED | Irradiance Source | 19 LED Bulbs (Built-in the center of each EEG electrode) |
Wavelength | Near-Infrared 850 nm | |
Pulse Rate | 1 – 45 Hz (Adjustable in 1Hz Increments) |
![](https://www.imedisync.com/wp-content/uploads/2022/12/sub_isyncwave_spec02-2.jpg)
![](https://www.imedisync.com/wp-content/uploads/2021/11/sub_isyncwave_spec02-3-1.jpg)
Parameters | Values |
---|---|
Name of Software | iSyncWave Download from google playstore |
Compatible Devices | Samsung Galaxy Tab S6(Lite), S7, S8 or Above *S7 FE specification exclusion |
OS | Android 11 or Above *The above specifications may differ from country to country, so it may be necessary to contactthe service center in the country concerned. |
Minimum Requirements | |
CPU | Octa-Core / 2.3 GHz, 1.7 GHz |
RAM | 4 GB |
Recommended Requirements | |
CPU | Octa-Core / 3.09 GHz, 2.4GHz, 1.8 GHz |
RAM | 12 GB |
